Double Inlet Centrifugal Blowers Manufacturer [Hetal Industries]

Dimensions as per Blower Models

Model A B C D E F G
DI133-S3 133 180 238 92 215 187 188
DI146-S6 146 180 251 105 232 236 226
DI160-S3 160 150 220 125 202 223 227
DI180-K3 180 210 285 180 260 308 300
DI180-K4 180 180 255 130 230 267 257
DI250-M7 250 250 328 198 300 395 390



Standard Models & Technical Specifications

Sr.
No.		 Model Volt
(V)		 Watts
(W)		 Current
(A)		 Speed
(rpm)		 Capacitor
(uF)		 Air Vol.
(CMH)		 Air Vol.
(CFM)		 Noise
(dBA)		 Nt. Wt.
(Kg.)
1 DI133-4E-S3 230 80 0.35 1400 3.15 475 280 67 4.5
2 DI133-2E-S3 230 180 0.73 1450 3.15 850 500 75 4.5
3 DI133-2D-S3 415 198 0.32 2150 – 925 545 75 4.5
4 DI146-2E-S6 230 365 1.5 1900 8 1350 795 75 7.2
5 DI146-2D-S6 415 365 0.6 2000 – 1300 765 75 7.2
6 DI160-4E-S3 230 115 0.47 1200 3.15 815 480 69 4.8
7 DI160-2E-S8 230 470 2.05 2300 10 1200 705 83 7.5
8 DI160-2D-S8 415 502 0.84 2300 – 1400 825 83 7.5
9 DI180-4E-K3 230 210 0.9 1000 5 1700 1000 68 8.5
10 DI180-4D-K3 415 250 0.45 1100 – 1700 1000 68 8.5
11 DI180-4E-K4 230 240 1.05 1300 6 1350 795 68 9
12 DI180-4D-K4 415 200 0.49 1400 – 1350 795 68 9
13 DI250-6E-M7 230 305 1.3 900 10 2350 1380 60 18.5
14 DI250-6D-M7 415 305 0.88 950 – 2400 1410 60 18.5
15 DI250-4D-M7 415 800 1.3 1250 – 3250 1910 72 18.5
